• Model : SRC3KUXI
• Power Rating : 3000VA (3KVA)
• Output power Max : 2400Watts
• UPS Type  : Online
• Waveform : Sine wave
• Battery Type  : External Battery
• Battery Volts  :  72V DC
• No of Battery  : 12V battery - 6 Nos
• Nominal Output Voltage : 230V
• Nominal Input Voltage : 230V
• Input Connections : 3 way Connector
• Output Connections  : 3 way Connector
• Application  : Server & Computers Load
• Warranty  : 2 years repair or replacement

3KVA SRC3KUXI Features

• Smart-UPS - Online High Density Double Conversion Technology
• Application - for Server/ Voice & Data/ Network/ MedicalLabs & Light Industrial
• Applications- Harsh environment Maximum Load Factor - 2400 Watts Efficiency 92.0% (at 100% load)
• Crest Factor - 3:1
• Sockets -2 IEC 320 C13 and 1 Hard Wire 3-wire (PN+G) (international PC connectors)
• Front Panel - LED+LCD Display
• Power Chute Software-Business Edition 5 Nodes-v9.1.1 for Windows Hyper-V, Red Hat Enterprise, Linux, VMware, Windows 2003,
• External batteries - Optional depending on required run time
• Built in Automatic Bypass
• Frequency and voltage regulation

  Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
• Safety-agency approved

  Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
• Resettable circuit breaker

  Easy recovery from overloads; no need to replace a fuse. (Not available on Wall Tap SKUs)
• Generator compatible

  Ensures clean, uninterrupted power to protected equipment when generator power is used.
• Cold-start capable

  Provides temporary battery power when the utility power is out.
• Power conditioning

  Protects connected loads from surges, spikes, lightning, and other power disturbances.
• Input power factor correction

  Minimizes installation costs by enabling the use of smaller generators and cabling.

3KVA SRC3KUXI Technical Specifications
