• Model : E3SUPS15KH 3PHASE
• Power Rating : 15000VA (15KVA)
• Output power Max : 15000Watts
• UPS Type  : Online
• Waveform : Sine wave
• Battery Type  : External Battery
• Battery Volts  :  394V DC
• No of Battery  : 12V battery - 32Nos
• Nominal Output Voltage : 400V 3PH
• Nominal Input Voltage : 400V 3PH
• Input Connections : Terminal Block
• Output Connections  : Terminal Block
• Application  : Server & Computers Load
• Warranty  : 1 year

EASY UPS 15KVA E3SUPS15KH Features- 3PHASE

• Double Conversion Mode (upto 96%)
• ECO Mode (99% Efficiency)
• Common Battery under 1+1mode
• Parallel upto 4 UPS
• Conformal Coating on PCBA
• In-built Replaceable Dust Filter
• Operating Temperature Up To 40C
• Output Power Capacity - 15.0 KW / 15.0 kVA Output Voltage THD - < 3% linear load
• Overload Operation - 150% for 1 min 125% for 10 min
• Bypass - Built-in Maintenance Bypass Maximum Input Current - 28 A
• Input Frequency - 45 - 65 Hz
• Input Total Harmonic Distortion - Less than 3% for full load
• Interface Port(s) - E3S_Parallel
• E3S_TempSensor
• 20% Power as Charging Capacity
• Mimic Panel Multi Language LCD Display (EPO Inbuilt)
• RoHS Compliance
• ECO Mode - Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
• Intuitive user interface - The intuitive graphical user interface allows for easy system configuration.
• Front-access servicing - Simplifies installation and UPS maintenance while minimizing space requirements.
• Straightforward installation - Including the input, output, and bypass breakers, as well as the Emergency Power Off (EPO) switch, simplifies installation planning and speeds up deployment.
• Easy Loop Test - Verifies UPS performance before you connect your load, without the need for a load bank.
• Easy to install fast - Quickly roll the compact and lightweight UPS into position.
• Wide Input Voltage Window - Saves your battery power for when you really need it - during power cuts!
• Parallel capability - Multiple units can be placed in parallel to meet power capacity and redundancy requirements
• Replaceable dust filters - protect the UPS in harsh environments.
• SNMP Card - Optional.

EASY UPS 15KVA E3SUPS15KH Technical Specifications - 3PHASE
